• Superior flexibility
Features
STAGES:
• Manual X-Y stage
• Motorised X-Y stage (optional)
• Motorised X-Y-Z stage (optional)
• INV system with Video filar level 1, 2, or 3 (optional)
• INV system with auto focus and auto measuring level 4 (optional)
TURRET SYSTEM:
• Fully automatic 4 position turret for Micro Vickers / Macro Vickers, Brinell or Knoop measurements
• Featuring 3 objectives at choice, all 3 objectives can be used for measuring and observation. Optional 2nd indenter position
INDENTERS:
• Vickers 136º
• Knoop 172.5º x 130º
• Brinell 1 & 2.5mm
EYEPIECE:
• Electronic eyepiece microscope with precision encoder providing 15x magnification
OBJECTIVES:
• 5x for 75x magnification
• 10x for 150x magnification
• 20x for 300x magnification
• 40x for 600x magnification
|
EW-4300 |
Vickers/Knoop |
1Kgf - 30Kgf
|
|
EW-4301 |
Brinell |
1Kgf - 31.25Kgf
|
|
EW-4302 |
Macro Vickers/Knoop |
300gf - 30Kgf
|
|
EW-4303 |
Micro/Macro Vickers/Knoop |
20gf - 30Kgf
|
|
EW-4304 |
Micro/Macro Vickers/Knoop/Brinell |
20gf - 31.25Kgf
|
|
EW-4500 |
Vickers/Knoop |
1Kgf - 50Kgf
|
|
EW-4501 |
Brinell |
1Kgf - 62.5Kgf
|
|
EW-4502 |
Macro Vickers/Knoop |
300gf - 50Kgf
|
|
EW-4503 |
Micro/Macro Vickers/Knoop |
100gf - 50Kgf
|
|
EW-4504 |
Micro/Macro Vickers/Knoop/Brinell |
100gf - 62.5Kgf |
